JKY50/50-40 clay brick making machine is mainly used in clay brick production line. It is also used to produce clay bricks. The processed pug is changed into the needed billets by the machine through the following steps in clay brick production line. It is mixed first, next treated by vacuum, then conveyed and squeezed by spiral reamer, finally extruded by a fixed shaped opening.  JKR55/50-40vacuum extruder for clay brick has the reasonable structure. Its extrusion pressure is very big and the biggest one is 3.5Mpa. Its yield is very high, 15000 to 18000 pieces every hour. At the same time, JKY 55/50-40 clay brick making machine is applicable for high vacuum, squeezing thin-walled and porous shale, and coal gangue and clay brick.

The main components are reducer, pneumatic clutch, gear box, stirred tank, vacuum box, and mold. The body of of JKY50/50-40clay brick making machine is all made of welded steel plates

Item
Unit of measurement
JKB55/50-30 clay brick making machine

Production capacity

standard brick(240*115*53mm)/hour
19600-23000
Reamer diameter
mm
550/500
Maximum extrusion pressure
Mpa
4.0
Vacuum degree
Mpa
≤-0.092
Power
KW
160+75
Overall size
mm
5500*5000*2500
Weight
t
22
